1XXA26000MAA,DSA221SDN晶振,KDS壓控溫補晶振
頻率：26M
尺寸：2520mm
1XXA26000MAA,DSA221SDN晶振,KDS壓控溫補晶振
KDS工業設備晶振,26.000MHz壓控溫補晶振(型號1XXA26000MAA),依托高精度溫補與壓控雙技術加持,頻率穩定度嚴苛控制在±2ppm(-40℃~+85℃),支持2.8V控制電壓下的精細頻率調節,可實時補償5G核心網設備,毫米波基站因溫度波動與信號干擾導致的頻率偏移.產品內置超低噪聲振蕩芯片,相位噪聲低至-145dBc/Hz@1kHz偏移,能保障高頻信號傳輸?shù)男旁氡?為5G網絡高速數據交互提供超可靠時鐘基準.
1XXA26000MAA,DSA221SDN晶振,KDS壓控溫補晶振
|
原廠型號 Originalmodel： |
1XXA26000MAA |
品牌brand： |
|
|
Manufacturer品牌 |
KDS |
OperatingTemperature溫度 |
-40C +85C |
|
Series型號 |
DSA221SDN |
Current-Supply(Max) |
- |
|
Type類型 |
PackageHeight高度 |
0.8mm |
|
|
Frequency頻率 |
26M |
Termination 腳位 |
4-pad |
|
輸出方式 Output： |
CMOS |
PackageType 封裝類型 |
4-Smd |
|
Voltage-Supply電壓 |
2.8V |
Packaging 包裝 |
TapeandReel |
|
FrequencyStability頻率穩定度 |
|
安裝方式 Installation： |
Surfacemount |
|
Size/Dimension尺寸 |
2520mm |
最小包裝數MPQ： |
3000 |
1XXA26000MAA,DSA221SDN晶振,KDS壓控溫補晶振
1XXA26000MAA,DSA221SDN晶振,KDS壓控溫補晶振
|
KDS |
7BH03276A0S |
DST1210A |
1210四腳 |
32.768K |
|
KDS |
7BG03276A25 |
DST1610A |
1610 |
32.768K |
|
KDS |
7BG03276A1X |
DST1610A |
1610 |
32.768K |
|
KDS |
1TJH090DP1A0006 |
DST1610A |
1610 |
32.768K |
|
KDS |
1TJ125DR1AC054 |
DST210AC |
2012 |
32.768K |
|
KDS |
7BF03276A3K |
DST210AC |
2012 |
32.768K |
|
KDS |
1TJE090FR1AH00C |
DST410S |
4115 |
32.768k |
|
KDS |
32ETJS070FJ |
DT-26 |
206 |
32.768KHZ |
|
KDS |
1TC125DFNS004 |
DT-38 |
308 |
32.768k |
|
KDS |
1TC125DFNS008 |
DT-38 |
308 |
32.768KHZ |
|
KDS |
1TC125JHNS010 |
DT-38 |
308 |
32.768KHZ |
|
KDS |
1ZZNAE38400AB0A |
DSX211SH |
2016 |
38.400M |
|
KDS |
7AE01200A00 |
DSX221G |
2520 |
12.000M |
|
KDS |
7AD00800A1Y |
DSX321G |
3225 |
8.000M |
|
KDS |
1C208000CE0R 汽車 |
DSX321G |
3225 |
8.000M |
|
KDS |
7AD00800A1X汽車 |
DSX320GE |
3225 |
8.000M |
|
KDS |
1ZCM08000EE0A汽車 |
DSX320G |
3225 |
8.000M |
|
KDS |
1C208000EZ0G汽車 |
DSX321G |
3225 |
8.000M |
|
KDS |
1N210000EE0X |
DSX321G |
3225 |
10.000M |
|
KDS |
1C213080CC0A |
DSX321G |
3225 |
13.080M |
|
KDS |
1C232000ABOV |
DSX321G |
3225 |
32.000M |
|
KDS |
1N254000BB0M |
DSX321G |
3225 |
54.000M |
|
KDS |
1ZCM12000BC0A |
DSX320G |
3225 |
12.000M |
|
KDS |
1C216000EE0AW |
DSX321G |
3225 |
16.000M |
|
KDS |
1N216000EE0BE |
DSX321G |
3225 |
16.000M |
|
KDS |
1N238400AB0C |
DSX321G |
3225 |
38.400M |
|
KDS |
1C220000EE0BF |
DSX321G |
3225 |
20.000M |
|
KDS |
1C220000AA0K |
DSX321G |
3225 |
20.000M |
|
KDS |
1C224000BE0K |
DSX321G |
3225 |
24.000M |
|
KDS |
7AD02500A4K |
DSX321G |
3225 |
25.000M |
|
KDS |
1N225000BC0CT |
DSX321G |
3225 |
25.000M |
|
KDS |
1N225500CC0A |
DSX321G |
3225 |
25.500M |
|
KDS |
1P227120BE0A |
DSX321G |
3225 |
27.120M |
|
KDS |
1BASAMPLE |
DSX321G |
3225 |
27.000M |
|
KDS |
1N224000BC0BS |
DSX321G |
3225 |
24.000M |
|
KDS |
1C224000AA0AD |
DSX321G |
3225 |
24.000M |
|
KDS |
7AD01228A0H |
DSX321G |
3225 |
12.288M |
|
KDS |
7AD02400A3D |
DSX321G |
3225 |
24.000M |
|
KDS |
7AD04800A0T |
DSX321SH |
3225 |
48.000M |
|
KDS |
7AF05000A0B |
DSX211G |
2016 |
50.000M |
|
KDS |
7BG03276A2X |
DST1610A |
1610 |
32.768KHZ |
|
KDS |
7FD05000A0S |
DSO321SR |
3225 |
50.000M |
|
KDS |
1N228636AB0B |
DSX321G |
3225 |
28.63636M |
|
KDS |
1TJG090DP1AC015 |
DST210AC |
2012 |
32.768K |
|
KDS |
1XSE100000AR30 |
DSO321SR |
3225 |
100.000M |
|
KDS |
1XSF10000AH |
DSO221SH |
2520 |
10.000M |
|
KDS |
CW08000EK3B |
DSX151GAL |
11.8*5.5 |
8.000M |
|
KDS |
1AJ160005BE |
SMD-49 |
|
16.000M |
|
KDS |
1AJ245763ED |
SMD-49 |
11*4.6 |
24.576M |
|
KDS |
1AC080005BM |
AT-49 |
11*4.6 |
8.000M |
|
KDS |
SB103CE1MM |
SINGLE |
|
|
|
KDS |
1RAK38400CRB |
DSR211STH |
2016 |
38.400M |
|
KDS |
7FG00003A03 |
DSO1612AR |
1612 |
32.768KHZ |
|
KDS |
1XSF016000EH |
DSO221SHF |
2520 |
16.000M |
|
KDS |
7FE02496A00 |
DSO221SX |
2520 |
24.96M |
|
KDS |
7EF01000A03 |
DSB211SDN |
2016 |
10.000M |
|
KDS |
1XXD26000MLP |
DSB211SDN |
2016 |
26.000M |
|
KDS |
1XXD40000PDA |
DSB211SDN |
2016 |
40.000M |
|
KDS |
7EF01600A00 |
DSB211SDN |
2016 |
16.000M |
|
KDS |
1XXD52000PBA |
DSB211SDN |
2016 |
52.000M |
